Jaw Crusher PULVERISETTE 1 premium line

code : PULVERISETTE 1

The extra powerful premium pre-crusher

The extra powerful FRITSCH Jaw Crusher PULVERISETTE 1 premium line with its up to 3 kW drive power ensures an exceptionally high throughput and is the ideal instrument for fast and effective pre-crushing - batchwise or continuous – of hard or very hard brittle materials even hardest ferrous alloys!
The FRITSCH Jaw Crusher PULVERISETTE 1 premium line is ideal for a max. feed size of 95 mm and a max. continuous throughput of up to 250 kg/h depending on the material and gap setting.

Feed size up to 95 mm – max. continuous througphut 250 kg/h
Extra powerful motor with up to 3 kW drive power
Outstanding noise reduction due to side walls insulated with foam for a significantly quieter operation
Especially safe as drawer and grinding chamber lid lock automatically
Funnel folds away completely providing easy access and easy to fill
Freely accessible grinding chamber
Clean Design: smooth surfaces in the grinding chamber enable easy cleaning and prevent cross-contamination
Extremely heavy-duty plexiglas cover for visual inspection of grinding chamber
Automatic adjustment of correct direction of rotation - optimal results for three-phase versions
Zero-point adjustment can be calibrated: compensation of wear of crushing jaws, precise re-adjustment after turning/ replacing crushing jaws
Progressive gap adjustment: zero point adjustment can be calibrated is connected with a progressive grinding gap adjustment.
Extra low noise and dust-free operation
Lateral support walls especially easy to replace, crushing jaws easily removable
Combinable with the Disk Mill PULVERISETTE 13 premium line

TECHNICAL DATA

Working principle	pressure
Optimal for material type	very hard, hard, medium-hard, brittle and abrasive samples and for metal-free grinding
Grinding tools	fixed and movable crushing jaws
Materials of the grinding tools	hardened steel, stainless steel, chromium-free tool steel, manganese steel, hardmetal tungsten carbide, zirconium oxide
Max. feed size (depending on material)	95 mm
Min. sample quantity	20 ml
Max. continuous throughput (depends on material and gap width)	250 kg/h
Final fineness	0.3 - 15 mm
Feeding	batchwise/continuous
Eccentric oscillations	308 movements/min
Electrical Details*(other voltages available on request)	400 V/3~, 50/60 Hz, 3490 Watt
Instrument also available in the following voltage	200 V/3~, 50/60 Hz, 3490 Watt - order no. 01.2040.00
Emission sound pressure level at the workplace according to DIN EN ISO 3746 (depending on the material to be crushed)	approx. LpAd = 83 dB
Weight	320 kg
Dimensions (W x D x H)	bench top instrument 55 x 90 x 106 cm

*The three-phase AC version„/3~“ is definitely preferable over a single-phase version „/1~“, since you obtain with the three-phase AC version more power, better effectiveness and a greater energy efficiency.

Please note: the three-phase AC version „/3~“ must always be operated on a three-phase supply network.
