Mobile Design
Spectroscopy can now be taken anywhere. The optional integrated battery pack provides up to 10 hours of stand-alone battery powered operation.
-
+2-35734687
-
sales@technoscientific.net
Stay Connected:
+2-35734687
sales@technoscientific.net
Stay Connected:
Spectroscopy can now be taken anywhere. The optional integrated battery pack provides up to 10 hours of stand-alone battery powered operation.
Spectroscopy can now be taken anywhere. The optional integrated battery pack provides up to 10 hours of stand-alone battery powered operation.
Designed for open measurements: don’t lose time with closing a lid for each reading. Ideal for all UV/Vis spectroscopy applications including kinetics. Cuvette holder optimized for all standard cuvettes (quartz, glass and plastic) with a center height of 8.5 mm
Turn on and instantly measure without lamp warm-up time. Full scan capability from 200 - 900 nm provides rapid and complete sample analysis in only 3.5 seconds.
Built-in computer with a high performance dual core Q7 quad core 1 GHz processor and 32 GB of onboard memory provides powerful analysis and easy storage of methods and data.
Equipped with Wi-Fi, built-In HotSpot, LAN, HDMI and USB A/B interface connections for remote instrument control, data accessibility and printing. NPOS now supports AirPrint /IPP compatible printers supporting PDF format, printers compatible with the HP universal driver and DYMO label printers (cryo and standard labels). The NanoPhotometer® is compatible with 1 and 2D bar code readers allowing for flexible and streamlined data entry. Unique file server functionality allows access of data stored on the NanoPhotometer® drive from any computer accessing the lab network.
Every NanoPhotometer® is able to generate formatted Excel and PDF document files for data processing or archiving of measurements on the lab network. The capability to print full page reports, labels and cryo labels via USB and through a network connection lends users the upmost flexibility for data output. Supported printers include AirPrint/IPP compatible printers supporting PDF format, printers with HP universal printer driver capability and DYMO label printers.
AirPrint® is a registered trademark of Apple Inc. Cupertino, CA
Malware, viruses and ransomware are serious threats to instrumentation working on Android or Windows based platforms. The proprietary NanoPhotometer® Operating System NPOS protects data in a secure environment immune to known malicious software. Whether running Apps on the NanoPhotometer/control device or downloading precious measurement results, your data is safe. For additional security the NanoPhotometer® does not allow browsing on the internet whilst providing safe access to control devices like computers, tablets and smart phones.
NPOS now offers the user interface in a selection of languages. The advanced language functionality allows the operator to effectively understand and interact with the unit, boosting productivity in the lab. In addition to a new multilingual user interface, the NanoPhotometer® provides the flexibility to print results in multiple languages, which prevents misinterpretation of data and time consuming translations. The selection covers most widely spoken languages including English, Chinese, French, German, Japanese, Portuguese, Russian, and Spanish and will be continuously extended.
Mobile and easy control of the NanoPhotometer® is possible via Wi-Fi from tablets or smartphones (Android OS & iOS). Easy control from PCs (Windows & Mac) with fast and flexible connection options including Wi-Fi, USB and LAN.
Learn more >Sealed optics without any moving parts eliminates the need for costly and time consuming recalibrations. Durable, inert surfaces provide an easy to clean maintenance free design. Compatible with Worldwide Pharmacopeia Requirements. 1.8 nm bandwidth built in. IQ/OQ package available.
Learn more >Preprogrammed Apps for common UV/Vis spectroscopy applications including kinetics and dedicated LifeSciences package come standard with each instrument.
Affordable custom app development to create your personalized spectrophotometer
Easily convert your NanoPhotometer® C40 cuvette spectrophotometer into a nanovolume spectrophotometer with the sub-micro liter cell from Implen. With as little as 0.3 µl sample volume, samples can now be virtually diluted and analyzed directly. There are a variety of path-lengths that can be utilized with the sub-microliter cell to provide virtual sample dilution including 2 mm, 1 mm, 0.5 mm, 0.1 mm and 0.004 mm.
3.8-5.2 kg depending on configuration
1 GHz
1024 x 600 pixels; Touch-Screen glove compatible
Optional rechargeable lithium ion battery; 95Wh, 6.6Ah; Operation time: up to 10 h; min. charging cycles: 800
| Detection Range dsDNA | 0.1 ng/µl to 130 ng/µl |
| Detection Range BSA | 0.003 mg/ml to 3.7 mg/ml |
| Photometric Range | 0.002 – 2.6 A |
| Center Height (Z-Height) | 8.5 mm |
| Cell Types | outside dimension 12.5 x 12.5 mm |
| Heating | 37°C ± 0.5°C |
| Wavelength Scan Range | 200 – 900 nm |
| Measure Time For Full Scan Range | 3.5 seconds |
| Wavelength Reproducibility | ± 0.2 nm |
| Wavelength Accuracy | ± 0.75 nm |
| Bandwidth | 1.8 nm |
| Stray Light | < 0.5% at 220 nm using NaI |
| Absorbance Reproducibility | 0.002 (both paths) @ 280 nm |
| Absorbance Accuracy | ±0.002 A or ±1% of the reading, whichever is the greater |
| Zero Stability | ±0.003 A/hour after 20 min warm up @ 280 nm |
| Noise |
0.002 A rms at 0 A @ 280 nm 0.002 A (pk to pk) at 0 A @ 280 nm |
| Optical Arrangement | 1 x 3648 CCD Array |
| Lamp | Xenon flash lamp |
| Lifetime | 109 flashes, up to 10 years |
| Control Options | Onboard with built-in touch screen, computer, smartphone and tablet |
| Software Compatibility | Windows 7, 8, 10 (32 & 64 bit), OS X, iOS and Android OS |
| Min. Requirement Smart Phone/Tablet |
4 inch screen Apple: iPad 2, iPhone5 and iOS 6 Android Phone: OS Version 4.4 Android Tablet: OS version 5.0, Quadcore 1.2 GHz with 1 GB RAM |
