Series UF V | Ultralow temperature freezers with VIP insulation and electromechanical door lock

code : UFV700

Important characteristics

  • Temperature range: -40 °C to -86 °C
  • Refrigeration with cascade compressor refrigeration unit
  • CFC-free safety refrigerants R-404A and R-508B
  • Door hinged right or left
  • RFID controlled Access (depending on version)
  • Data Logger USB (depending on version)
  • Water cooling (depending on version)
  • Electromechanical door latch
  • 4 compartment doors made of ABS plastic
  • Inner chamber made of stainless steel
  • Thermal insulation using vacuum insulating panels and PUR foam
  • Battery-backed alarm system
  • Computer interface: RS 422
  • Analog output, 4 – 20 mA
  • Zero-voltage alarm contact
  • Elapsed time indicator
  • 3 stainless steel shelves

Select version
Rated voltage Option model Version Art. No. MSRP*[?] Selection Bookmark
Model UF V 700
208…240 V 1~ 60 Hz

Door hinged right, data logger USB

 UFV700UL-240V-R¹ 9020-0238 - +

Door hinged left, data logger USB

 UFV700UL-240V-L¹ 9020-0216 - +
120 V 1~ 60 Hz

Door hinged right, data logger USB

 UFV700UL-120V-R¹ 9020-0239 - +

Door hinged left, data logger USB

 UFV700UL-120V-L¹ 9020-0218 - +
230 V 1~ 50 Hz

Door hinged right, RFID system

 UFV700-230V-R¹ 9020-0233 - +

Door hinged left, RFID system

 UFV700-230V-L¹ 9020-0237 - +

Door hinged right, Water cooling, RFID system

 UFV700-230V-RW¹ 9020-0261 - +

Door hinged left, Water cooling, RFID system

 UFV700-230V-LW¹ 9020-0262 - +
* Recommended retail price



Designation UFV700UL-240V-R¹ UFV700UL-240V-L¹ UFV700UL-120V-R¹ UFV700UL-120V-L¹ UFV700-230V-R¹ UFV700-230V-RW¹ UFV700-230V-L¹ UFV700-230V-LW¹
Option model Door hinged right, data logger USB Door hinged left, data logger USB Door hinged right, data logger USB Door hinged left, data logger USB Door hinged right, RFID system Door hinged right, Water cooling, RFID system Door hinged left, RFID system Door hinged left, Water cooling, RFID system
Order number 9020-0238 9020-0216 9020-0239 9020-0218 9020-0233 9020-0261 9020-0237 9020-0262
Measures
Interior volume [L] 711 711 711 711 711 711 711 711
Net weight of the unit (empty) [kg] 360 360 360 360 360 360 360 360
permitted load [kg] 200 200 200 200 200 200 200 200
Permitted load of individual compartment [kg] 65 65 65 65 65 65 65 65
Load per rack [kg] 50 50 50 50 50 50 50 50
Doors
Unit doors 1 1 1 1 1 1 1 1
Internal Dimensions
Width [mm] 911 911 911 911 911 911 911 911
Height [mm] 1300 1300 1300 1300 1300 1300 1300 1300
Depth [mm] 600 600 600 600 600 600 600 600
Outer dimensions
Width net [mm] 1120 1120 1120 1120 1120 1120 1120 1120
Height net [mm] 1985 1985 1985 1985 1985 1985 1985 1985
Depth net [mm] 885 885 885 885 885 885 885 885
Wall clearance back [mm] 100 100 100 100 100 100 100 100
Wall clearance sidewise [mm] 175 175 175 175 175 175 175 175
Environment-specific data
Energy consumption at set-point -80 °C and ambient temperature = 25 °C (+/- 10 %) [kWh/d] 14.9 14.9 12.5 12.5 13.9 13.9 13.9 13.9
Sound-pressure level [dB(A)] 49 49 49 49 49 49 49 49
Fixtures
Number of shelves (std./max.) 3/7 3/7 3/7 3/7 3/7 3/7
